FiTech EV1 LS Injector Sub Harness Set (70050-4-2)

FiTech EV1 LS Injector Sub Harness Set (70050-4-2) are essential components designed to facilitate the connection of fuel injectors to the main wiring harness within a FiTech LS Fuel Injection system. This product provides a reliable and direct electrical pathway, ensuring optimal performance and fuel delivery for multi-port injection setups. Sold as a pair, these sub-harnesses are specifically tailored for integration with FiTech’s advanced LS engine management systems.

KEY FEATURES AND BENEFITS:

• Direct Compatibility: Engineered specifically for seamless integration with FiTech LS Fuel Injection systems, ensuring a perfect fit and reliable operation.
• Complete Pair: Sold as a pair, providing the necessary connections for both banks of a typical V8 engine, simplifying the installation process.
• Multi-Port Design: Supports multi-port fuel injection styles, a common configuration for modern LS engines, ensuring accurate fuel delivery to each cylinder.
• Speed Density Metering: Designed for systems utilizing speed density fuel management, which calculates air mass based on manifold absolute pressure and engine speed.
• Reliable Connection: Provides a secure and stable electrical connection between the fuel injectors and the main wiring harness, minimizing the risk of intermittent issues or signal loss.
• Simplified Installation: Offers a straightforward connection point, making the installation of the fuel injection system more manageable, especially when using compatible FiTech components.
• Quality Construction: Manufactured to meet FiTech’s standards for performance and reliability, ensuring long-term functionality within the demanding engine environment.

SPECIFICATIONS:

• Brand: FiTech Fuel Injection
• Manufacturer Part Number: 70050-4-2
• Product Line: FiTech Fuel Injector Sub-Harnesses
• Fuel Injection Style: Multi-port
• Metering Style: Speed density
• Quantity: Sold as a pair
• Compatibility: Designed for use with FiTech LS Fuel Injection systems.
• UPC: 812061034685

HOW TO USE:

• Preparation: Ensure the engine is turned off and the FiTech LS Fuel Injection system is partially installed, with the main wiring harness accessible.
• Locate Injector Connectors: Identify the fuel injector connectors on your engine.
• Connect Sub-Harness to Injectors: Take one FiTech 70050-4-2 sub-harness and connect the appropriate end to the fuel injectors on one bank of the engine. Ensure a secure and proper connection.
• Connect Sub-Harness to Main Harness: Connect the other end of the sub-harness to the corresponding connector on the FiTech LS main wiring harness. Match the connectors carefully to avoid damage.
• Repeat for Other Bank: Take the second FiTech 70050-4-2 sub-harness and repeat steps 3 and 4 for the fuel injectors on the other bank of the engine.
• Verify Connections: Double-check all connections to ensure they are firmly in place and properly seated.
• System Check: Once all connections are made, proceed with the final steps of installing and setting up your FiTech LS Fuel Injection system as per the manufacturer’s instructions.

BENEFITS OF USING FITECH EV1 LS INJECTOR SUB HARNESS SET (70050-4-2):

• Utilizing the FiTech 70050-4-2 Fuel Injector Sub-Harnesses offers several key advantages for those installing or maintaining a FiTech LS Fuel Injection system.
• Ensures a reliable and compatible connection between the fuel injectors and the system’s main wiring.
• Direct compatibility eliminates guesswork and potential wiring issues that can arise from using generic or incorrect harnesses.
• Sold as a pair, simplifying the process for V8 engine setups by providing all the necessary connections in one package.
• Supports multi-port fuel injection and speed density metering, tailored to the specific requirements of many LS engine configurations using FiTech systems.
• Contributes to a smoother installation process and ensures optimal performance and longevity of the fuel injection system.

FEATURES:

• Engineered for FiTech LS Systems: Specifically designed to integrate seamlessly with FiTech LS Fuel Injection systems.
• Complete Set for V8 Engines: Includes two sub-harnesses, catering to the needs of typical V8 engine configurations.
• Facilitates Multi-Port Injection: Designed to support the wiring requirements of multi-port fuel injection setups.
• Compatible with Speed Density: Ensures proper electrical connections for speed density fuel management systems.
• Direct Connection Interface: Provides a dedicated and secure connection point for fuel injectors.
• Simplifies Wiring: Streamlines the wiring process between the injectors and the main harness.
• Durable Construction: Built with quality materials to withstand the engine environment.
• Identifiable Connectors: Features connectors designed to match those on the fuel injectors and the main harness, aiding in correct installation.
